[Disclaimer]

I struggled a lot with writing this article, as K8S itself is way too big to grasp quickly and I had to make a lot of compromises on the structure and details for it all to make some sense. The article may feel dragged in some places, jumping from topic to topic yet I had to complete it, so sorry not sorry.

GenAI has been used to generate the diagrams from the Kubernetes, Container-D and RunC codebase.

Specific commit hashes used for analysis:

Kubernetes - 19aa01e61cf ContainerD - cd0f2cc23 RunC - b04031d7

Introduction

So, we’ve through quite a journey. We’ve be able to track down how signals help us to clean-up resources before the imminent death. We’ve also peeked through the keyhole at how layered the containerization software is right now and were able to find how signals passing works as well!

Now let’s approach the arch-nemesis, the kubernetes, with the same question: how does the graceful shutdown works within it?

Kubernetes itself is quite a difficult beast to overview, with an abundance of abstractions, interfaces, configurations.

At its core, Kubernetes provides a way to:

• Deploy containerized applications across a cluster of machines (nodes)
• Scale applications up and down horizontally and vertically
• Ensure high availability through automatic failover
• Handle networking between applications
• Manage storage and configuration
• Provide abstraction layer on top of cloud providers / raw hardware infrastructure

When you deploy an application to Kubernetes, you’re not directly interacting with containers or individual machines. Instead, you declare the desired state of your application (number of replicas, resource requirements, etc.) and Kubernetes handles the nitty-gritty details of scheduling and maintaining that state.

Let’s dive into the key abstractions of Kubernetes responsible for the graceful shutdown.

Understanding Pods: What We’re Actually Shutting Down

Before diving into the shutdown mechanics, let’s clarify what exactly we’re terminating. A pod in Kubernetes isn’t just a single container - it’s actually a collection of containers working together as a single unit.

Pod Components:

• Pause container: The infrastructure container that creates shared namespaces
• Application containers: Your actual workload (web server, API, etc.)
• Sidecar containers: Supporting services (logging, monitoring, service mesh)

Shared Resources: All containers in a pod share the same network IP, storage volumes, and inter-process communication channels. This means when we “shut down a pod,” we’re coordinating the termination of multiple processes that are dependent on one another.

Kubernetes Architecture for Graceful Shutdown

Kubernetes has lots of components provides comprehensive coverage, but let’s focus on what matters for the pod termination:

Control Plane Components:

• API Server: The central communication hub that coordinates all shutdown activities
• Controller Manager: Manages higher-level constructs like Deployments and Services
• Endpoint Controller: Updates network routing when pods terminate

Worker Node Components:

• kubelet: The node agent that manages pod lifecycles and executes termination
• kube-proxy: Updates network rules to redirect traffic away from terminating pods
• Container Runtime: The actual executor of container start/stop operations

The graceful shutdown process orchestrates across all these components to ensure both proper process termination and network traffic management.

Network Traffic Management During Shutdown

I’m working mostly on backend systems and web applications are of my uttermost interest. For this case graceful shutdown involves two parallel concerns: actually terminating the application process cleanly AND makig sure network traffic is properly managed.

When a pod shuts down, we need to:

1. Stop new traffic from reaching the shutting down pod
2. Allow existing connections to complete gracefully (at least as much as we can)
3. Coordinate timing between network updates and process termination

How Kubernetes Solves This:

EndpointSlices and Traffic Redirection: Kubernetes uses EndpointSlice objects to track which pods can receive traffic. When a pod begins terminating, the Endpoint Controller immediately updates the EndpointSlice with:

endpoints:
- addresses: ["10.244.1.5"]
  conditions:
    ready: false       # Stop new traffic
    serving: true      # Allow existing connections
    terminating: true  # Pod is shutting down

Load Balancer Coordination: Different components handle the transition differently:

• kube-proxy: Updates iptables rules to redirect new connections
• Ingress Controllers: May implement custom connection draining logic
• External Load Balancers: Need time to detect changes (hence PreStop hooks)
• Service Mesh: Advanced traffic management during termination

This networking orchestration happens in parallel with process termination, ensuring zero-downtime deployments when configured properly.

Now that we understand the components and networking coordination involved, let’s examine how to configure graceful shutdown properly.

Configuring Graceful Shutdown in Kubernetes

The magic happens through specific configuration settings in your Kubernetes manifests. Here’s how to configure the key graceful shutdown aspects:

apiVersion: apps/v1
kind: Deployment
metadata:
  name: web-app
spec:
  replicas: 3
  strategy:
    type: RollingUpdate
    rollingUpdate:
      maxSurge: 1
      maxUnavailable: 0  # CRITICAL: Prevents traffic disruption during deployments
  selector:
    matchLabels:
      app: web-app
  template:
    metadata:
      labels:
        app: web-app
    spec:
      # CORE GRACEFUL SHUTDOWN SETTING: Time allowed for complete shutdown
      terminationGracePeriodSeconds: 60

      containers:
      - name: app
        image: my-web-app:latest
        ports:
        - containerPort: 8080

        # PRESTOP HOOK: Coordinates with load balancer updates
        lifecycle:
          preStop:
            exec:
              # We can trigger some app before the SIGTERM comes
              command: ["/bin/sh", "-c", "sleep 15"]

        # READINESS PROBE: Controls when pod receives traffic
        readinessProbe:
          httpGet:
            path: /health/ready
            port: 8080
          periodSeconds: 5
          failureThreshold: 1  # Fast removal from endpoints when unhealthy

Graceful Shutdown Configuration Breakdown:

• terminationGracePeriodSeconds: 60: Total time Kubernetes waits before SIGKILL. This is your shutdown budget - choose based on your longest-running requests plus buffer time.

• preStop hook with 15s delay: Critical for web apps. This delay ensures load balancers detect the pod is terminating and stop sending new traffic BEFORE your application receives SIGTERM. This may be the place where we can define custom shutdown logic in case we don’t have a SIGTERM processing logic. The example may include waiting some time to finish processing already running processes, signal the cluster regarding the possible rebalance, persist some in-memory state, etc. Important: If the preStop hook runs longer than the grace period, kubelet requests a small 2-second extension, but if it still doesn’t complete, emergency termination occurs.

• maxUnavailable: 0: Forces rolling updates to start new pods before terminating old ones. Combined with readiness probes, this ensures zero-downtime deployments.

• readinessProbe with failureThreshold: 1: Fast endpoint removal when app becomes unhealthy. During shutdown, your app should fail readiness checks immediately after receiving SIGTERM to stop new traffic.

Timing Relationship:

t=0s:   preStop hook starts (sleep 15)
t=15s:  SIGTERM sent to application
t=60s:  SIGKILL sent if still running

Your app has 45 seconds (t=15s to t=60s) to drain connections and shut down gracefully.

With the configuration basics covered, let’s dive into the technical implementation details. We’ll trace the complete journey from command execution to signal delivery.

The Graceful Shutdown Flow: From kubectl to kill()

The following breakdown shows the complete pod termination flow from kubectl delete to process termination:

Phase 1 - Initial Request: User executes kubectl delete pod my-app. API Server marks pod for deletion in etcd and triggers parallel workflows: Controller Manager removes pod from ReplicaSet while Endpoint Controller updates networking.

Phase 2 - Networking Updates: Endpoint Controller marks pod as ready: false, serving: true, terminating: true. Load balancers immediately stop routing new traffic while existing connections continue.

Phase 3 - kubelet Coordination: kubelet receives deletion event, calculates grace period (30s default), and executes PreStop hooks if defined. This provides critical time for load balancer updates.

Phase 4 - Signal Delivery: kubelet initiates the CRI chain: kubelet → containerd → containerd-shim → runc → SIGTERM to process 1 inside each container. For pods with sidecar containers, main containers receive SIGTERM first, then sidecars are terminated in reverse order.

Phase 5 - Connection Draining: Application stops accepting new requests but completes existing ones. If graceful exit succeeds, cleanup begins. If grace period expires, SIGKILL forces termination.

Phase 6 - Cleanup: Process termination status propagates back to kubelet and API Server. kubelet transitions the pod to a terminal phase (Failed or Succeeded), then forcibly removes the pod object from the API server by setting grace period to 0. Endpoint is removed from EndpointSlice and load balancers complete updates.

This orchestrated shutdown maintains web application availability during deployments and scaling operations.

// setTerminationGracePeriod determines the grace period to use when killing a container
func setTerminationGracePeriod(pod *v1.Pod, containerSpec *v1.Container, containerName string, containerID kubecontainer.ContainerID, reason containerKillReason) int64 {
	gracePeriod := int64(minimumGracePeriodInSeconds)
	switch {
	case pod.DeletionGracePeriodSeconds != nil:
		return *pod.DeletionGracePeriodSeconds
	case pod.Spec.TerminationGracePeriodSeconds != nil:
		switch reason {
		case reasonStartupProbe:
			if isProbeTerminationGracePeriodSecondsSet(pod, containerSpec, containerSpec.StartupProbe, containerName, containerID, "StartupProbe") {
				return *containerSpec.StartupProbe.TerminationGracePeriodSeconds
			}
		case reasonLivenessProbe:
			if isProbeTerminationGracePeriodSecondsSet(pod, containerSpec, containerSpec.LivenessProbe, containerName, containerID, "LivenessProbe") {
				return *containerSpec.LivenessProbe.TerminationGracePeriodSeconds
			}
		}
		return *pod.Spec.TerminationGracePeriodSeconds
	}
	return gracePeriod
}

// Run the pre-stop lifecycle hooks if applicable and if there is enough time to run it
if containerSpec.Lifecycle != nil && containerSpec.Lifecycle.PreStop != nil && gracePeriod > 0 {
    gracePeriod = gracePeriod - m.executePreStopHook(ctx, pod, containerID, containerSpec, gracePeriod)
}

// waitForTurn waits until it is time for the container with the specified name to begin terminating, up until
// the specified grace period.  If gracePeriod = 0, there is no wait.
func (o *terminationOrdering) waitForTurn(name string, gracePeriod int64) float64 {
	// if there is no grace period, we don't wait
	if gracePeriod <= 0 {
		return 0
	}

	start := time.Now()
	remainingGrace := time.NewTimer(time.Duration(gracePeriod) * time.Second)

	for _, c := range o.prereqs[name] {
		select {
		case <-c:
		case <-remainingGrace.C:
			// grace period expired, so immediately exit
			return time.Since(start).Seconds()
		}
	}

	return time.Since(start).Seconds()
}

err := m.runtimeService.StopContainer(ctx, containerID.ID, gracePeriod)

// Phase 1: Send SIGTERM (or custom signal)
stopSignal := getStopSignal(container)  // Default: "SIGTERM"
sig, err := signal.ParseSignal(stopSignal)
task.Kill(ctx, sig)

// Wait for graceful shutdown
timeout := time.Duration(t) * time.Second
ctx, cancel := context.WithTimeout(ctx, timeout)
exitCh, err := task.Wait(ctx)

select {
case <-exitCh:
    // Container exited gracefully
case <-ctx.Done():
    // Timeout - force kill with SIGKILL
    task.Kill(ctx, syscall.SIGKILL)
}

func (p *Init) Kill(ctx context.Context, signal uint32, all bool) error {
    return p.runtime.Kill(ctx, p.id, int(signal), &runc.KillOpts{All: all})
}

func (p *setnsProcess) signal(sig os.Signal) error {
    return p.cmd.Process.Signal(sig)  // Go standard library
}
